Mastercam 2018 Mill

Mastercam 2018 Mill

April 13, 2018

CNC Software Inc./Mastercam

http://www.mastercam.com
Software

Tolland, Connecticut – Mastercam 2018 Mill offers expanded machining flexibility and an increased emphasis on speed and automation. Two-dimensional high-speed toolpaths, 3D enhancements, and multi-axis features combine with dozens of additional new enhancements in a package intended to improve shop floor productivity. Here are some highlights and new functionality in Mastercam Mill:

2D enhancements
Stock awareness has been added to select 2D toolpaths and allows tool motion on the top, bottom, or both values of the stock. This provides a safer and more optimized tool motion. You can also optimize finish passes based on your rough stock, giving you more efficient and safer tool motion. Plunge entry is supported for Dynamic Mill toolpaths, allowing you to plunge directly into material. Spring passes can be used to create additional finish passes with a spacing of zero between the passes. This can be used for parts with thin material that may have flexed away from the tool during previous passes.

3D enhancements
The workflow for all 3D high speed toolpaths has been streamlined and gives you fine control over exactly where to cut. High speed Hybrid toolpaths now offer smoothing controls and deliver a finer finish, requiring less handwork. Follow containment has been added and allows the tool to follow the containment boundary back to the start of the cut, creating clean and closed passes. It also helps to avoid partial cuts when a containment boundary was directly on top of a vertical surface.

Multi-axis improvements
Common direction has been added to select toolpaths and keeps the tool at a uniform tilt angle to reduce tool and machine motion. Dropping has been added to the 3- to 5-axis toolpaths and projects the 3-axis toolpath onto the selected surfaces, adjusting the tool vectors to be normal to the surface. Also, the Multi-axis Link Safety Zone page has been redesigned to better reflect the parameters.

Additional powerful tools in Mastercam 2018 Mill include:

  • Contour enhancements such as chamfer tool offset, machine finish passes, multi-pass order, and rough pass cut direction
  • Mastercam 2D toolpaths now support depth cut direction and depth cut order, allowing users to order cuts from top to bottom or from bottom to top, as well as allowing users to set the depth cut order
  • When selecting an undercut tool, but not wanting to machine the undercut area; detect undercuts disables undercutting when using an undercut tool
  • Collision Control redesigned in Mastercam Multi-axis, and Maintain Tilt keeps the tool tilted during retract and feed moves to reduce tool and machine motion
