Gage thread inspection system

Gage thread inspection system

July 11, 2018

Johnson Gage

http://www.johnsongage.com
Quality/Metrology

Bloomfield, Connecticut – Johnson Gage will display will be the JCR Runout and Concentricity Inspection System for verification of cylindrical runout at IMTS 2018 Booth #135305. The JCR can be used stand-alone or with an optical comparator for verification of geometries in cutting tool product. The JCR incorporates precision datum rolls, a unique upper tension roll assembly, and integral axial stop pins to assure proper part staging and absolute gage accuracy. In addition, the company will feature its Thread Inspection System for the verification and in-process control of reverse-angle buttress threads commonly used in anti-splaying medical devices such as orthopedic implants.
