CGTech’s Vericut version 9.1

CGTech’s Vericut version 9.1

July 13, 2020

CGTech

https://www.cgtech.com
Software

CGTech has released the latest Vericut software, Version 9.1. Vericut CNC machine simulation, verification, and optimization software simulates all types of CNC machining, additive, and hybrid manufacturing processes. The software operates independently but can also be integrated with leading CAM systems.
Vericut 9.1 raises the bar for CNC simulation once again with several new cutting-edge features that increase efficiency and empower users to do more in less time. New visibility options, plus enhancements to toolpath optimization, additive manufacturing (AM), tooling & multi-tool stations, measuring & inspection/reporting are just a few of the noteworthy features in this latest release. Hundreds of customer-driven improvements and software requests were also incorporated in this latest version.
Enhanced visibility
New visibility features have been added to the Project Tree and Vericut’s right-click convenience menus for components and models, enabling users to toggle between visible and invisible states, or to enable/disable 3-D objects for the simulation. New features have also been added to Auto-Diff giving users a higher degree of control over component visibility, such as when fixture models should appear.
X-caliper Annotated Images
Setup Plan has been renamed to Annotated Images. Vericut Inspection is also now included with Annotated Images. Both Setup Plan and Inspection functionality are greatly enhanced with dimensions, notes, and tolerances for checking parts at various stages of machining. Easily create professional looking and informative setup plans and inspection images stored with view layouts - ready to print as “shop aid” documents, or to appear in Vericut’s comprehensive reports.
Shanks in cutting tool assemblies
Defining shanks as separate objects from the holder and cutter enables programmers to see where these non-cutting portions of the cutter are relative to the stock workpiece, and allows more discrete control over near miss and collision detection properties and tolerances. Tool holder models can also be used as “Shanks”.
Streamlined optimization with AI
The Optimize Control window has been streamlined to fit in a single window with no tabs. Relevant features become active in subsections depending on which Mode is selected. A new Force “Learn” Mode is available, providing artificial intelligence (AI) for optimization. In Learn mode, Vericut learns from simulating cutting, then automatically configures and optimizes tools for increased cutting efficiency and reduced machining times.
Force charts
New “Save All As” Optimization Settings option added to the right mouse menu when clicking on a Force Chart. New ability to ‘Learn From Results’ enables optimization settings for a tool or all tools that were analyzed.
Additive manufacturing
Vericut 9.1 has a new “Additive” Default Machining Type. This enables Vericut to predict system resources that will be needed to additively build the as-designed part, including a starting stock build plate or model. Vericut can build multiple parts created by a “nested” build NC program, enabling additively built parts to be independently relocated or assembled for finish machining, or exported. This feature is especially helpful for big area additive manufacturing (BAAM) and large scale additive manufacturing (LSAM) parts.
DXF import
The DXF import feature has been enhanced with several new features. The DXF reader can now read the layers within a DXF file and automatically detect CUT/NOCUT layers. Additional layers can be checked on to use as additional components.
