TDK Corporation’s TDK-Lambda brand CUS400M AC-DC power supply series, in the industry standard 3" x 5" footprint, are rated at 400W with forced air and can continuously deliver 250W, with peaks of up to 400W for 30 minutes when convection or conduction cooled. These power supplies are ideal for applications with occasional peak demands, including hospital beds, dental chairs, and other motor driven products.
The CUS400M meets curve B conducted and radiated EMI in either a Class I or Class II (double insulated) construction, without the need for external filtering of shielding. The CUS400M series accepts an 85VAC to 264VAC input and is available with 12V and 24V outputs initially, with 15V, 19V, 28V, 36V, and 48V models following shortly. A 5V 2A or 12V 0.83A standby voltage, remote on/off, remote sense, DC Good and AC Fail signals can be specified as an option.
The power supplies are available with multiple mechanical configurations. Open frame, metal baseplate, U channel, and enclosed models are in production now, with the top fan version coming later in the year. The open frame CUS400M measures 77.5mm x 128mm x 39.5mm (W x L x H). The operating ambient temperature is -20°C (-30°C start-up) to 70°C, derating linearly above 50°C to 50% load.
The CUS400M has an input to output isolation of 4,000VAC (2 x MoPP), an input to ground isolation of 1,500VAC (1 x MoPP) and an output to ground isolation of 1,500VAC (1 x MoPP) for suitability in B and BF rated medical equipment. The leakage current is <250µA and touch current is <100µA. The maximum operating, transportation, and storage altitude is 5,000m.
Safety certifications include IEC/EN/ES 60601-1, IEC/EN/UL 62368-1 and IEC/EN/UL 60950-1 with CE marking for the Low Voltage, EMC, and RoHS Directives. The units also comply with EN 55011-B and EN 55032-B conducted and radiated emissions (Class I and II), and meet the EN 61000-3-2 harmonics, IEC60601-1-2 Edition 4, and IEC 61000-4 immunity standards.
Main features and benefits
- 400W with forced air cooling
- 250W convection/conduction cooled with a 400W peak for extended time periods
- Medical certifications (2 x MoPP input to output)
- Class B conducted and radiated EMI
- Suitable for Class I and Class II installations
- Compact 3" x 5" footprint
